Gorbel 1000 Ibs. Aluminum Gantry Crane ALUG-1000-6/9-8

$3,132.62

  • 1000 lbs.
  • Hub 7′ 6″ (Min)  10′ 6″ (Max)
  • Span 10′
  • I-Beam Depth (W) 5″
  • Tread Depth is 51″ for all models
  • Trolley Travel (T) 7′ 9-3/4″
  • OAH 10′ 11″
  • Weight 227
  • 4-6 weeks lead time

Made from lightweight extruded materials, the components of the Adjustable Height Aluminum Gantry Crane are easily lifted by one person. This provides cost-effective shipment to a job site, and allows for ease of use in a multitude of work areas—for example, carrying material up a ladder or staircase to a rooftop work area.

  • Lightweight – easily move for use in any location in your facility
  • Square tubing uprights and channel base – provides stability when lifting loads and during movements
  • Adjustable Height and Span – provides maximum lift in many applications and can easily be adjusted to fit any span
  • Collapsible for easy storage – doesn’t take up valuable production space – when not in use
SKU: ALUG-1000-6/9-8 Category:

Description

  • 1000 lbs.
  • Hub 7′ 6″ (Min)  10′ 6″ (Max)
  • Span 10′
  • I-Beam Depth (W) 5″
  • Tread Depth is 51″ for all models
  • Trolley Travel (T) 7′ 9-3/4″
  • OAH 10′ 11″
  • Weight 227
  • 4-6 weeks lead time

Made from lightweight extruded materials, the components of the Adjustable Height Aluminum Gantry Crane are easily lifted by one person. This provides cost-effective shipment to a job site, and allows for ease of use in a multitude of work areas—for example, carrying material up a ladder or staircase to a rooftop work area.

  • Lightweight – easily move for use in any location in your facility
  • Square tubing uprights and channel base – provides stability when lifting loads and during movements
  • Adjustable Height and Span – provides maximum lift in many applications and can easily be adjusted to fit any span
  • Collapsible for easy storage – doesn’t take up valuable production space – when not in use

Freight will be added at time of purchase based on current market value.

Additional information

Weight 213 lbs
Manufacturer

Gorbel

Span

10 ft

HUB

7 ft 6 in min 10ft 6 in max

Gantry Capacity

1000 lbs
